3D scanners
High-Speed Terrestrial Laser Scanner
1 MHz scanner, 360° × 282° field of view
- Speed
- 1000 kHz
- FOV
- 360° × 282°
- Laser
- Class 1
3D Laser Scanners
Terrestrial 3D Laser Scanner
Compact terrestrial scanner, 2 Mpts/s
A compact 4.4 kg terrestrial scanner that captures up to 2 million points per second with HDR colour, available in 70 m, 150 m and long-range versions. It is the tool we recommend for building interiors, plant rooms, accident scenes and BIM as-builts.
- Speed
- 2 Mpts/s
- Range
- 70–150 m+
- Weight
- 4.4 kg
- Up to 2 million points per second
- 70 m, 150 m and long-range versions
- HDR colour up to 266 MPx
- Only 4.4 kg including battery
- 230 × 183 × 103 mm
- WLAN and USB
MOQ 1 unitVolume pricing available
1-year warrantyLifetime remote support
Ships in 3–7 daysExpress, air or sea
OEM & ODMLogo, colour, packaging
Overview
Range: 0.5–70 m or 0.5–150 m (90 % reflectivity) depending on version; the long-range version reaches 614 m at 0.5 Mpts/s, 307 m at 1 Mpts/s and 153 m at 2 Mpts/s.
An integrated 13 MPx HDR camera (2×, 3×, 5× brackets) colours the point cloud at up to 266 MPx. Control the scanner by WLAN from a tablet or export via USB.
Applications
- BIM & as-built
- Industrial plants
- Heritage documentation
- Forensics
- Facility management
Related
Specifications
| Measurement speed | Up to 2 Mpts/s |
|---|---|
| Range | 0.5–70 m / 0.5–150 m (white, 90 %) |
| Long-range version | 614 m @ 0.5 Mpts/s; 307 m @ 1 Mpts/s; 153 m @ 2 Mpts/s |
| Colour | Up to 266 MPx |
| HDR camera | 13 MPx, 2×/3×/5× brackets |
| Interface | WLAN, USB |
| Weight | 4.4 kg including battery |
| Dimensions | 230 × 183 × 103 mm |
| Warranty | 1 year |
Need the full datasheet?
We send PDF datasheets, manuals and software details for each batch, together with your quotation.
Request datasheet and priceSpecifications are typical values and may change with product updates. Accuracy depends on satellite geometry, multipath, baseline length and correct set-up.
Terrestrial 3D Laser Scanner questions
Not answered here? Ask our engineers.
What are the payment and shipping terms for the Terrestrial 3D Laser Scanner?
MOQ is one unit. We accept T/T and quote EXW, FOB Shanghai, CIF or DAP. Stock units usually ship in 3–7 working days by express, air or sea freight, with a one-year warranty.
