S20 GNSS Smart Antenna
Model S20 · RTK receiver + antenna for vehicles
S20 combines an RTK receiver and a full-band antenna in one weatherproof radome for mounting on tractors, sprayers and work vehicles. It is the positioning heart of guidance and autosteer systems.
- Channels
- 1408
- Protection
- IP67
- Temp.
- −45 to +75 °C
- Receiver and antenna in one housing
- 1408-channel full-constellation RTK
- IP67, −45 °C to +75 °C
- Bluetooth output
- For tractors, sprayers and vehicles
- OEM integration
MOQ 1 unitVolume pricing available
1-year warrantyLifetime remote support
Ships in 3–7 daysExpress, air or sea
OEM & ODMLogo, colour, packaging
Overview
Rated IP67 and −45 °C to +75 °C, it is built for years on a cab roof. Bluetooth connects it to a tablet or display; OEM integration for machine-control makers is available.
Applications
- Tractor guidance
- Auto-steering
- Vehicle navigation
- Machine control
Related
Specifications
| Type | RTK GNSS receiver with integrated antenna |
|---|---|
| Channels | 1408 |
| Satellites | GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC, SBAS |
| Connectivity | Bluetooth |
| Ingress protection | IP67 |
| Operating temperature | −45 °C to +75 °C |
| Warranty | 1 year |
Need the full datasheet?
We send PDF datasheets, manuals and software details for each batch, together with your quotation.
Request datasheet and priceSpecifications are typical values and may change with product updates. Accuracy depends on satellite geometry, multipath, baseline length and correct set-up.
S20 questions
Not answered here? Ask our engineers.
What are the payment and shipping terms for the S20?
MOQ is one unit. We accept T/T and quote EXW, FOB Shanghai, CIF or DAP. Stock units usually ship in 3–7 working days by express, air or sea freight, with a one-year warranty.
